| Nama Wahi | LSM490YP01 |
| Waitohu | SAMSUNG |
| Rahi | 49 |
| Taupānga | Desktop Monitor |
| Whakatau | 3840×1080 |
| Te tito | a-Si TFT-LCD, CELL |
| Tirohanga | |
| CR | 3000:1 |
| Nga Tae | 1.07B |
| Whakamuri | No |
| Atanga | eDP |
| panel brand | SAMSUNG |
| panel model | LSM490YP01 |
| panel size | 49" |
| panel type | a-Si TFT-LCD, CELL |
| resolution | 3840(RGB)×1080, 81PPI |
| pixel format | RGB Vertical Stripe |
| display area | 1195.78(W)×336.31(H) mm |
| bezel opening | - |
| outline size | 1208.18(W)×350.012(H) ×1.11(D) mm |
| surface | Antiglare (Haze 25%) |
| brightness | 0 cd/m² |
| contrast ratio | 3000:1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| display mode | SVA, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 8 (Typ.)(G to G |
| glass depth | 0.40+0.40 mm |
| transmissivity | 4.1% (Typ.)(with Polarizer) |
| display colors | 1.07B |
| lamp type | No B/L |
| frequency | 144Hz |
| touch screen | - |
| driver ic | COF Built-in 12 source chips |
| panel weight | 1.30Kgs (Max.) |
| application | Desktop Monitor |
| signal interface | eDP (8 Lanes) , HBR1 (2.7G/lane) , 51 pins Connector |
| input voltage | 12.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
