Nama Wahi | LC490DUY-SHA1 |
Waitohu | LG Display |
Rahi | 49 |
Taupānga | LCTV |
Whakatau | 1920×1080 |
Te tito | CELL |
Tirohanga | 0 |
CR | 1200:1 |
Nga Tae | 16.7M |
Whakamuri | No B/L |
Atanga | LVDS |
panel brand | LG Display |
panel model | LC490DUY-SHA1 |
panel type | a-Si TFT-LCD , CELL |
panel size | 49 inch |
resolution | 1920(RGB)×1080 , FHD |
display mode | IPS, Normally Black, Transmissive |
active area | 1073.78×604 mm |
outline | 1085.5×617.7 mm |
surface | Antiglare (Haze 1%), Hard coating (3H) |
transmissivity | 6.61% (Typ.)(with Polarizer) |
contrast ratio | 1200:1 (Typ.) |
display colors | 16.7M (8-bit) |
response time | 6 (Typ.)(G to G) |
viewing angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
signal interface | LVDS (2 ch, 10-bit), 51 pins |
input voltage | 12.0V (Typ.) |
application | LCTV |
