V315B6-L04

V315B6-L04
V315B6-L04
V315B6-L04
V315B6-L04 thumb V315B6-L04 thumb V315B6-L04 thumb
Waitohu
Innolux
Rahi
31.5
Taupānga
LCTV
Whakatau
1366×768
Te tito
LCM
Tirohanga
350
CR
2300:1
Nga Tae
16.7M
Whakamuri
CCFL
Atanga
LVDS
In Stock
11348
Whakatakotoranga

Nama Wahi V315B6-L04
WaitohuInnolux
Rahi31.5
TaupāngaLCTV
Whakatau1366×768
Te titoLCM
Tirohanga350
CR2300:1
Nga Tae16.7M
WhakamuriCCFL
AtangaLVDS
panel brandCHIMEI INNOLUX
panel modelV315B6-L04
panel type a-Si TFT-LCD , LCM
panel size31.5 inch
resolution1366(RGB)×768 , WXGA
display modeSuper MVA, Normally Black, Transmissive
active area697.685×392.256 mm
outline760×450 mm
surfaceAntiglare (Haze 11%), Hard coating (3H)
brightness350 cd/m² (Typ.)
contrast ratio2300:1 (Typ.)
display colors16.7M (8-bit), CIE193172%
response time8.5 (Typ.)(G to G)
viewing angle88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
frequency60Hz
lamp type3 pcsCCFLEmbedded (Balance board)
signal interfaceLVDS (1 ch, 8-bit), 30 pins
input voltage12.0V (Typ.)
applicationLCTV
