| Nama Wahi | LS013B7DH07 |
| Waitohu | Sharp |
| Rahi | 1.26 |
| Taupānga | Wearable Electronic |
| Whakatau | 144×168 |
| Te tito | CG-Silicon, LCM |
| Tirohanga | |
| CR | 20:1 |
| Nga Tae | Monochrome |
| Whakamuri | No |
| Atanga | 3-wire |
| brand | Sharp |
| model | LS013B7DH07 |
| diagonal size | 1.26 inch |
| type | CG-Silicon, LCM |
| pixel format | 144×168 175PPI |
| configuration | Rectangle |
| active area | 20.88(H)×24.36(V) mm |
| outline dim. | 24.68(H)×30(V) mm |
| bezel area | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | - |
| contrast ratio | 20:1 (Typ.) (RF) |
| view direction | - |
| response time | 10/20 (Typ.)(Tr/Td) |
| viewing angle | 60/60/60/60 (Typ.)(CR≥2) |
| operating mode | Transflective |
| support color | Monochrome |
| light source | No B/L |
| weight | 1.10g (Max.) |
| designed for | Wearable Electronic Price Tag |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | 3-wire SPI , 11 pins FPC |
| power supply | 3.3/3.3V (Typ.)(VDDA/VDD) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
