| Nama Wahi | LQ035Q7DB02R |
| Waitohu | SHARP |
| Rahi | 3.5 |
| Taupānga | HHP |
| Whakatau | 240×320 |
| Te tito | LCM |
| Tirohanga | 50 |
| CR | 70:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ035Q7DB02R |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 3.5 inch |
| resolution | 240(RGB)×320 , QVGA |
| display mode | TN, Normally White, Transflective |
| active area | 53.64×71.52 mm |
| outline | 65×85×4.8 mm |
| surface | Hard coating (3H) |
| brightness | 50 cd/m² (Typ.) |
| contrast ratio | 70:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| display colors | 262K (6-bit) |
| response time | 30/50 (Typ.)(Tr/Td) |
| viewing angle | 40/40/40/50 (Typ.)(CR≥2)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 50 pins |
| input voltage | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| application | HHP |
