LM220WE5-TLA1

LM220WE5-TLA1
LM220WE5-TLA1
LM220WE5-TLA1 thumb LM220WE5-TLA1 thumb
Waitohu
LG Display
Rahi
22.0
Taupānga
DMPC
Whakatau
1680×1050
Te tito
LCM
Tirohanga
250
CR
1000:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
1214
Whakatakotoranga

Nama Wahi LM220WE5-TLA1
WaitohuLG Display
Rahi22.0
TaupāngaDMPC
Whakatau1680×1050
Te titoLCM
Tirohanga250
CR1000:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandLG Display
panel modelLM220WE5-TLA1
panel type a-Si TFT-LCD , LCM
panel size22.0 inch
resolution1680(RGB)×1050 , WSXGA+
display modeTN, Normally White, Transmissive
active area473.76×296.1 mm
outline493.7×320.1 mm
surfaceAntiglare, Hard coating (3H)
brightness250 cd/m² (Typ.)
contrast ratio1000:1 (Typ.)
display colors16.7M (6-bit + Hi-FRC)
response time1.3/3.7 (Typ.)(Tr/Td)
viewing angle85/85/75/85 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type9S6PWLEDWithout Driver
signal interfaceLVDS (2 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
Tauira Whanau
LM220W1-A2MN LG Display 22.0 1600×1024
LM220WE1-TLB2 LG Display 22.0 1680×1050
LM220WE1-TLB3 LG Display 22.0 1680×1050
LM220WE1-TLD2 LG Display 22.0 1680×1050
LM220WE1-TLE2 LG Display 22.0 1680×1050
LM220WE1-TLK1 LG Display 22.0 1680×1050
LM220WE1-TLM1 LG Display 22.0 1680×1050
LM220WE1-TLP1 LG Display 22.0 1680×1050
LM220WE3-TLA1 LG Display 22.0 1680×1050
LM220WE5-TLA1 LG Display 22.0 1680×1050
