| Nama Wahi | LM12S49 |
| Waitohu | SHARP |
| Rahi | 12.1 |
| Taupānga | IA |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 185 |
| CR | 40:1 |
| Nga Tae | Color |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LM12S49 |
| panel type | CSTN-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | STN, Normally Black, Transmissive |
| active area | 246×184.5 mm |
| outline | 275×202.5×8.5 mm |
| surface | |
| brightness | 185 cd/m² (Typ.) |
| contrast ratio | 40:1 (Typ.) |
| display colors | Color |
| response time | 220/80 (Typ.)(Tr/Td) |
| viewing angle | 30/30/15/25 (Typ.)(CR≥5)(L/R/U/D) |
| frequency | 120Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | CMOS/TTL (1 ch, 8-bit), 41 pins |
| input voltage | 3.3/5.0V (Typ.)(VDD) |
| application | IA |
