| Nama Wahi | LH480HX1-SD01 |
| Waitohu | LG Display |
| Rahi | 4.8 |
| Taupānga | MPH |
| Whakatau | 480×1024 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 700:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | LG Display |
| panel model | LH480HX1-SD01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.8 inch |
| resolution | 480(RGB)×1024 |
| display mode | IPS, Normally Black, Transmissive |
| active area | 51.84×110.592 mm |
| outline | 57.64×121.45 mm |
| surface | |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 16.2M (6-bit + Dithering), CIE193168% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| input voltage | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| application | MPH |
