Nama Wahi | LD320DUE-FHB1 |
Waitohu | LG Display |
Rahi | 31.5 |
Taupānga | PID |
Whakatau | 1920×1080 |
Te tito | LCM |
Tirohanga | 400 |
CR | 1100:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | LVDS |
panel brand | LG Display |
panel model | LD320DUE-FHB1 |
panel type | a-Si TFT-LCD , LCM |
panel size | 31.5 inch |
resolution | 1920(RGB)×1080 , FHD |
display mode | S-IPS, Normally Black, Transmissive |
active area | 698.4×392.85 mm |
outline | 723.4×422.9 mm |
surface | Antiglare (Haze 1%), Hard coating (3H) |
brightness | 400 cd/m² (Typ.) |
contrast ratio | 1100:1 (Typ.) |
display colors | 16.7M (8-bit), CIE193168% |
response time | 10 (Typ.)(G to G) |
viewing angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
lamp type | 18S1PWLEDWithout Driver |
signal interface | LVDS (2 ch, 8-bit), 51 pins |
input voltage | 12.0V (Typ.) |
application | PID |
