| Nama Wahi | LD420WUB-SCC1 |
| Waitohu | LG Display |
| Rahi | 42 |
| Taupānga | PID |
| Whakatau | 1920×1080 |
| Te tito | LCM |
| Tirohanga | 1000 |
| CR | 1200:1 |
| Nga Tae | 16.7M/1.06B |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | LG Display |
| panel model | LD420WUB-SCC1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 42 inch |
| resolution | 1920(RGB)×1080 , FHD |
| display mode | S-IPS, Normally Black, Transmissive |
| active area | 930.24×523.26 mm |
| outline | 956.4×549.4×54.5 mm, Videowall Seam 26.2 mm |
| surface | Antiglare (Haze 10%), Hard coating (3H) |
| brightness | 1000 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) |
| display colors | 16.7M/1.06B (8-bit / 8-bit + Dithering) |
| response time | 9 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8/10-bit), 51 pins |
| input voltage | 12.0V (Typ.) |
| application | PID |
