Nama Wahi | LC151X01-C3P1 |
Waitohu | LG Display |
Rahi | 15.1 |
Taupānga | LCTV |
Whakatau | 1024×768 |
Te tito | LCM |
Tirohanga | 400 |
CR | 350:1 |
Nga Tae | 16.2M |
Whakamuri | CCFL |
Atanga | LVDS |
panel brand | LG.Philips LCD |
panel model | LC151X01-C3P1 |
panel type | a-Si TFT-LCD , LCM |
panel size | 15.1 inch |
resolution | 1024(RGB)×768 , XGA |
display mode | TN, Normally White, Transmissive |
active area | 307.2×230.4 mm |
outline | 352×263.5 mm |
surface | Antiglare (Haze 13%), Hard coating (3H) |
brightness | 400 cd/m² (Typ.) |
contrast ratio | 350:1 (Typ.) |
display colors | 16.2M (6-bit + FRC) |
response time | 7/18 (Typ.)(Tr/Td) |
viewing angle | 75/75/50/75 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
lamp type | 4 pcsCCFLWithout Driver |
signal interface | LVDS (1 ch, 8-bit), 20 pins |
input voltage | 5.0V (Typ.) |
application | LCTV |
