Nama Wahi | G151EVN01.0 |
Waitohu | AUO |
Rahi | 15.1 |
Taupānga | IA |
Whakatau | 1280×248 |
Te tito | LCM |
Tirohanga | 300 |
CR | 2000:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | LVDS |
panel brand | AUO |
panel model | G151EVN01.0 |
panel type | a-Si TFT-LCD , LCM |
panel size | 15.1 inch(1/4 cut of 19.0") |
resolution | 1280(RGB)×248 |
display mode | MVA, Normally Black, Transmissive |
active area | 376.32×72.91 mm |
outline | 396×100.8 mm |
surface | Antiglare, Hard coating (3H) |
brightness | 300 cd/m² (Typ.) |
contrast ratio | 2000:1 (Typ.) |
display colors | 16.7M (8-bit), CIE193170% |
response time | 15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
lamp type | WLEDEmbedded (LED Driver) |
signal interface | LVDS (2 ch, 8-bit), 30 pins |
input voltage | 5.0V (Typ.) |
application | IA |
