| Nama Wahi | LB170E01-SL01 |
| Waitohu | LG Display |
| Rahi | 17.0 |
| Taupānga | IA |
| Whakatau | 1280×1024 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | LG Display |
| panel model | LB170E01-SL01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×1024 , SXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 337.92×270.336 mm |
| outline | 368×306×14.8 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 13/9 (Typ.)(Tr/Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | IA |
| B170PW03 V1 | AUO | 17.0 | 1440×900 |
| CLAA170EA07 | CPT | 17.0 | 1280×1024 |
| G170J1-LE1 | Innolux | 17.0 | 1920×1200 |
| LB170E01-SL01 | LG Display | 17.0 | 1280×1024 |
| LC170WXL-SAA1 | LG Display | 17.0 | 1366×768 |
| M170E8-L01 | Innolux | 17.0 | 1280×1024 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| M170EG01 VH | AUO | 17.0 | 1280×1024 |
| M170ETN01.1 | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| AA104XD12--G1 | Mitsubishi | 10.4 | 1024×768 |
| G065VN01 V0 | AUO | 6.5 | 640×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| G104SN02 V2 | AUO | 10.4 | 800×600 |
| LQ084V1DG21 | SHARP | 8.4 | 640×480 |
| LQ190E1LW01 | SHARP | 19.0 | 1280×1024 |
| NL6448BC33-64D | NLT | 10.4 | 640×480 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
| TM150TDSG70 | Tianma | 15.0 | 1024×768 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
