| Nama Wahi | LB070WV8-SL02 |
| Waitohu | LG Display |
| Rahi | 7.0 |
| Taupānga | Industrial Automotiv |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | LG Display |
| model name | LB070WV8-SL02 1 Compatible |
| screen size | 7.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 152.4 × 91.44 (H×V) |
| outline(mm) | 170 × 106.3 × 10.7 (H×V×D) |
| bezel area(mm) | 155.2 × 94.2 (H×V) |
| treatment | Antiglare |
| luminance | 450 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10) |
| response | 15/10 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | IPS, Normally Black, Transmissive |
| color depth | 16.7M 60% NTSC |
| backlight | WLED , 50K hours , With LED Driver |
| mass | 220g (Max.) |
| used for | Industrial Automotive Display Gaming |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 80 °C |
