| Nama Wahi | KCG057QV1DL-G770 |
| Waitohu | Kyocera |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 320×240 |
| Te tito | CSTN-LCD, LCM |
| Tirohanga | |
| CR | 55:1 |
| Nga Tae | Color |
| Whakamuri | CCFL |
| Atanga | Parallel |
| brand | Kyocera |
| model | KCG057QV1DL-G770 |
| diagonal size | 5.7 inch |
| type | CSTN-LCD, LCM |
| pixel format | 320(RGB)×240 [QVGA] 70PPI |
| configuration | RGB Vertical Stripe |
| active area | 115.2(H)×86.4(V) mm |
| outline dim. | 144(H)×104.8(V) ×15.3(D) mm |
| bezel area | 119.4(H)×90.6(V) mm |
| treatment | Hard coating (2H) |
| luminance | - |
| contrast ratio | 55:1 (Typ.) (TM) |
| view direction | - |
| response time | 180/170 (Typ.)(Tr/Td) |
| viewing angle | 50/50/20/35 (Typ.)(CR≥2) |
| operating mode | STN, Normally Black, Transmissive |
| support color | Color |
| light source | CCFL [1 pcs] |
| weight | 220g (Typ.) |
| designed for | Industrial |
| frame rate | 75Hz |
| touch panel | 4-wire Resistive Touch |
| interface type | Parallel Data (1ch, 8-bit) Connector |
| power supply | 3.3/5.0V (Typ.)(VDD) |
| environment | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
