| Nama Wahi | HSD088IPW1-B00 |
| Waitohu | HannStar |
| Rahi | 8.8 |
| Taupānga | Automotive Display |
| Whakatau | 1920×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| manufacturer | HannStar |
| model name | HSD088IPW1-B00 |
| screen size | 8.8 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1920×480(RGB) 222PPI |
| arrangement | RGB Horizontal Stripe |
| active area(mm) | 218.88 × 54.72 (H×V) |
| outline(mm) | - |
| luminance | - |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | IPS Pro, Normally Black, Transmissive |
| color depth | 16.7M 50% NTSC |
| backlight | WLED , 30K hours , No Driver |
| mass | - |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | MIPI (4 data lanes) , 40 pins Connector |
| voltage supply | 3.3/12.0/20.0/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| LQ088H9DR01U | SHARP | 8.8 | 640×240 |
| LQ088H9DZ03 | SHARP | 8.8 | 640×240 |
| LQ088Y3DG01 | SHARP | 8.8 | 800×480 |
| S088WX03 | CDTECH | 8.8 | 1280×320 |
| T-51965GD088ZU-MFW-AEN | Kyocera | 8.8 | 640×240 |
