| Nama Wahi | H546DLK01.0 |
| Waitohu | AUO |
| Rahi | 5.5 |
| Taupānga | Mobile Phone |
| Whakatau | 1080×1920 |
| Te tito | AM-OLED , OLED |
| Tirohanga | |
| CR | 10000:1 |
| Nga Tae | 16.7M |
| Whakamuri | self |
| Atanga | MIPI |
| panel brand | AUO |
| panel size | 5.5" |
| resolution | 1080(RGB)×1920, FHD, 403PPI |
| display area | 68.04(W)×120.96(H) mm |
| outline size | 70.84(W)×128.01(H) ×0.92(D) mm |
| brightness | 350 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (Min.)(CR≥1600) |
| best view on | Symmetry |
| display colors | 16.7M 100% NTSC |
| frequency | 100Hz |
| driver ic | COG Built-in RM69071 |
| panel weight | - |
| signal interface | MIPI (4 data lanes) |
| input voltage | 1.8/3.1/5.8/4.6/-2.9V (Typ.)(IOVCC/VCI/AVDD/OVDD/OVSS) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | H546DLK01.0 |
| panel type | AM-OLED , OLED |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Hard coating (3H) |
| contrast ratio | 10000:1 (Min.) (TM) |
| display mode | - |
| response time | - |
| lamp type | self |
| touch screen | Embeded Touch |
| application | Mobile Phone |
