Nama Wahi | G260J1-L05 |
Waitohu | Innolux |
Rahi | 25.5 |
Taupānga | IA |
Whakatau | 1920×1200 |
Te tito | LCM |
Tirohanga | 350 |
CR | 1500:1 |
Nga Tae | 16.7M |
Whakamuri | CCFL |
Atanga | LVDS |
panel brand | CHIMEI INNOLUX |
panel model | G260J1-L05 |
panel type | a-Si TFT-LCD , LCM |
panel size | 25.5 inch |
resolution | 1920(RGB)×1200 , WUXGA |
display mode | Super MVA, Normally Black, Transmissive |
active area | 550.08×343.8 mm |
outline | 582×375.6 mm |
surface | Antiglare (Haze 25%), Hard coating (3H) |
brightness | 350 cd/m² (Typ.) |
contrast ratio | 1500:1 (Typ.) |
display colors | 16.7M (8-bit), CIE193192% |
response time | 15/5 (Typ.)(Tr/Td) |
viewing angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
lamp type | 16 pcsCCFLEmbedded (Inverter) |
signal interface | LVDS (2 ch, 8-bit), 30 pins |
input voltage | 5.0V (Typ.) |
application | IA |
