| Nama Wahi | G170HAN01.0 |
| Waitohu | AUO |
| Rahi | 17.0 |
| Taupānga | Industrial |
| Whakatau | 1920×1920 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 9S6P |
| Atanga | |
| panel brand | AUO |
| panel size | 17.0" |
| resolution | 1920(RGB)×1920, 159PPI |
| display area | 305.28(W)×305.28(H) mm |
| outline size | 325.01(W)×319.33(H) ×12.2(D) mm |
| brightness | 600 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 72% NTSC |
| frequency | 60Hz |
| weight | 1.20Kgs (Max.) |
| panel model | G170HAN01.0 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | AHVA, Normally Black, Transmissive |
| response time | 13/12 (Typ.)(Tr/Td) |
| lamp type | 9S6P WLED , 50K hours , With LED Driver |
| touch screen | Without |
| application | Industrial |
| G170J1-LE1 | Innolux | 17.0 | 1920×1200 |
| LB170X01-TL01 | LG Display | 17.0 | 1024×502 |
| LM170E01-TLB3 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ2 | LG Display | 17.0 | 1280×1024 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| M170E8-L01 | Innolux | 17.0 | 1280×1024 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| QD17EL07 Rev.09 | QDI | 17.0 | 1280×1024 |
| TD170WGCA1 | TPO | 17.0 | 1280×1024 |
