| Nama Wahi | G170ETN03.1 |
| Waitohu | AUO |
| Rahi | 17.0 |
| Taupānga | Industrial |
| Whakatau | 1280×1024 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AUO |
| model | G170ETN03.1 |
| diagonal size | 17.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×1024 [SXGA] 96PPI |
| configuration | RGB Vertical Stripe |
| active area | 337.92(H)×270.336(V) mm |
| outline dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| bezel area | 341.7(H)×274.1(V) mm |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | - |
| response time | 3.8/1.2 (Typ.)(Tr/Td) |
| viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 16.7M 72% NTSC |
| light source | WLED [9S4P] , 30K hours , W/O Driver |
| weight | 1.27Kgs (Typ.) |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| power supply | 5.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| CLAA170EA07Q | CPT | 17.0 | 1280×1024 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTA170D200F | TOSHIBA | 17.0 | 1280×1024 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-L01 | Samsung | 17.0 | 1920×1200 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
