Nama Wahi | G156XW01 V4 |
Waitohu | AUO |
Rahi | 15.6 |
Taupānga | Industrial |
Whakatau | 1366×768 |
Te tito | a-Si TFT-LCD , LCM |
Tirohanga | |
CR | 500:1 |
Nga Tae | 16.2M |
Whakamuri | WLED |
Atanga | |
panel brand | AUO |
panel size | 15.6" |
resolution | 1366(RGB)×768, WXGA, 100PPI |
display area | 344.232(W)×193.536(H) mm |
outline size | 363.8(W)×215.9(H) mm |
brightness | 500 cd/m² (Typ.) |
viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
best view on | - |
display colors | 16.2M 62% NTSC |
frequency | 60Hz |
weight | 860±40g |
panel model | G156XW01 V4 |
panel type | a-Si TFT-LCD , LCM |
pixel format | RGB Vertical Stripe |
bezel opening | 347.54(W)×196.83(H) mm |
surface | Antiglare, Hard coating (3H) |
contrast ratio | 500:1 (Typ.) (TM) |
display mode | TN, Normally White, Transmissive |
response time | 6/2 (Typ.)(Tr/Td) |
lamp type | WLED , 50K hours , With LED Driver |
touch screen | Without |
application | Industrial |
