Nama Wahi | G156HAN02.3 |
Waitohu | AUO |
Rahi | 15.6 |
Taupānga | Industrial Medical I |
Whakatau | 1920×1080 |
Te tito | a-Si TFT-LCD , LCM |
Tirohanga | |
CR | 1000:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | |
brand | AUO |
diagonal size | 15.6 inch |
pixel format | 1920(RGB)×1080 [FHD] 141PPI |
active area | 344.16(H)×193.59(V) mm |
bezel area | 347.06(H)×196.49(V) mm |
luminance | 500 cd/m² (Typ.) |
view direction | Symmetry |
viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
support color | 16.7M 99% sRGB |
weight | 600/660g (Typ./Max.) |
frame rate | 60Hz |
model | G156HAN02.3 |
type | a-Si TFT-LCD , LCM |
configuration | RGB Vertical Stripe |
outline dim. | 363.8(H)×215.9(V) ×9.3(D) mm |
treatment | Antiglare, Hard coating (3H) |
contrast ratio | 1000:1 (Typ.) (TM) |
response time | 25 (Typ.)(Tr+Td) |
operating mode | AHVA, Normally Black, Transmissive |
light source | WLED , 50K hours , With LED Driver |
designed for | Industrial Medical Imaging |
touch panel | Without |
