| Nama Wahi | G101EAN02.2 |
| Waitohu | AUO |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1280×800 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | G101EAN02.2 |
| panel size | 10.1" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1280(RGB)×800, WXGA, 149PPI |
| pixel format | RGB Vertical Stripe |
| display area | 216.96(W)×135.6(H) mm |
| bezel opening | - |
| outline size | 227.91(W)×148(H) ×7.75(D) mm |
| surface | Hard coating |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| display mode | AHVA, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 29 (Typ.)(Tr+Td) |
| display colors | 16.7M 50% NTSC |
| lamp type | WLED , 50K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 290g (Max.) |
| application | Industrial |
| signal interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
