| Nama Wahi | LP101WSA-TLB1 |
| Waitohu | LG Display |
| Rahi | 10.1 |
| Taupānga | NOPC |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 300:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | LG.Philips LCD |
| panel model | LP101WSA-TLB1 9 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.1 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 222.72×125.28 mm |
| outline | 235×143×5.2 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Antiglare |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 300:1 (Min.) |
| display colors | 262K (6-bit) |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 30/30/10/20 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.) |
| application | NOPC |
| LP101WH1-TLB1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLB3 | LG Display | 10.1 | 1024×576 |
| LP101WSA-TLN1 | LG Display | 10.1 | 1024×600 |
| LP101WX1-SLP2 | LG Display | 10.1 | 1280×800 |
| B089AW01 V1 | AUO | 8.9 | 1024×600 |
| BT101IW04 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA102NC01CW | CPT | 10.2 | 1024×600 |
| HSD101PFW3-A00 | HannStar | 10.1 | 1024×600 |
| LP101WSB-TLN1 | LG Display | 10.1 | 1024×600 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LTN116AT02-D01 | Samsung | 11.6 | 1366×768 |
| M101NWT2 R0 | IVO | 10.1 | 1024×600 |
| N101L6-L0A | Innolux | 10.1 | 1024×600 |
| N101L6-L0D | Innolux | 10.1 | 1024×600 |
