| Nama Wahi | ETM057010EDHU |
| Waitohu | EDT |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 640×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 350:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| panel brand | EDT |
| panel model | ETM057010EDHU |
| panel size | 5.7" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 640(RGB)×480, VGA, 141PPI |
| pixel format | RGB Vertical Stripe |
| display area | 115.2(W)×86.4(H) mm |
| bezel opening | - |
| outline size | 147.6(W)×100(H) ×11.7(D) mm |
| surface | - |
| brightness | 380 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) (TM) |
| viewing angle | 65/65/55/52 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 12 o'clock |
| response time | 15/35 (Typ.)(Tr/Td) |
| display colors | 16.7M 51% NTSC |
| lamp type | WLED , 30K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | PCAP |
| panel weight | - |
| application | Industrial |
| signal interface | Parallel RGB (1 ch, 8-bit) , 40 pins Connector |
| input voltage | 3.3/3.3V (Typ.)(VCC/VDD) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
