| Nama Wahi | DLC1010AZG-1 |
| Waitohu | Other |
| Rahi | 10.1 |
| Taupānga | CNS |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 1000 |
| CR | 250:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | DLC |
| panel model | DLC1010AZG-1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.1 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 222.72×125.28 mm |
| outline | 235×149.52 mm |
| surface | |
| brightness | 1000 cd/m² (Typ.) |
| contrast ratio | 250:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | |
| viewing angle | 85/85/85/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 3S16PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 3.3/10.5V (Typ.)(VCC/AVDD) |
| application | CNS |
