| Nama Wahi | CLAA101WK07 XN |
| Waitohu | CPT |
| Rahi | 10.1 |
| Taupānga | Automotive Display |
| Whakatau | 1280×720 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | CPT |
| diagonal size | 10.1 inch |
| pixel format | 1280(RGB)×720 [WXGA] 144PPI |
| active area | 224.64(H)×126.36(V) mm |
| bezel area | 227.64(H)×129.36(V) mm |
| luminance | 600 cd/m² (Typ.) |
| view direction | Symmetry |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| support color | 262K/16.7M 70% NTSC |
| weight | 430g (Typ.) |
| frame rate | 60Hz |
| model | CLAA101WK07 XN |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 238.8(H)×148.05(V) ×8.7(D) mm |
| treatment | Antiglare (Haze 25%), Hard coating (3H) |
| contrast ratio | 900:1 (Typ.) (TM) |
| response time | 25 (Typ.)(Tr+Td) |
| operating mode | HFFS, Normally Black, Transmissive |
| light source | WLED [6S5P] , 30K hours , W/O Driver |
| designed for | Automotive Display |
| touch panel | Without |
