| Nama Wahi | CLAA101FP0J XG |
| Waitohu | CPT |
| Rahi | 10.1 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1920×1200 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 750:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | CPT |
| panel model | CLAA101FP0J XG |
| panel size | 10.1" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×1200, WUXGA, 225PPI |
| pixel format | RGB Vertical Stripe |
| display area | 216.576(W)×135.36(H) mm |
| bezel opening | - |
| outline size | 228.99(W)×154.4(H) ×5.5(D) mm |
| surface | Antiglare, Hard coating |
| brightness | 1200 cd/m² (Typ.) |
| contrast ratio | 750:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | HFFS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 30 (Typ.)(Tr+Td) |
| display colors | 16.7M 50% NTSC |
| lamp type | WLED , 15K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | TBD |
| application | Industrial Outdoor High Brightness |
| signal interface | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -10 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
