| Nama Wahi | CLAA069LA0HCW |
| Waitohu | CPT |
| Rahi | 7.0 |
| Taupānga | Automotive Display |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | |
| panel brand | CPT |
| panel size | 7.0" |
| resolution | 800(RGB)×480, WVGA, 134PPI |
| display area | 156.6(W)×81.6(H) mm |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10) |
| best view on | 6 o'clock |
| display colors | 262K 70% NTSC |
| frequency | 60Hz |
| weight | 165g (Typ.) |
| panel model | CLAA069LA0HCW |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| display mode | TN, Normally White, Transmissive |
| response time | 20 (Typ.)(Tr+Td) |
| lamp type | WLED |
| touch screen | Without |
| application | Automotive Display |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
