| Nama Wahi | C084SAT01.1 |
| Waitohu | AUO |
| Rahi | 8.4 |
| Taupānga | Automotive Display |
| Whakatau | 800×600 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| manufacturer | AUO |
| screen size | 8.4 inch |
| pixel number | 800×600(RGB) (SVGA) 118PPI |
| active area(mm) | 170.88 × 128.16 (H×V) |
| luminance | - |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M |
| mass | - |
| refresh rate | 60Hz |
| max. ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 90 °C |
| model name | C084SAT01.1 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Horizontal Stripe |
| outline(mm) | - |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| response | 15/20 (Typ.)(Tr/Td) ms |
| work mode | AHVA, Normally Black, Transmissive |
| backlight | WLED , No Driver |
| used for | Automotive Display |
| touchscreen | Without |
| AA084SB11 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| M084GNS1 R1 | IVO | 8.4 | 800×600 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| T-51639D084JU-FW-A-AB | Kyocera | 8.4 | 1024×768 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
