| Nama Wahi | B156XTN07.0 HW1A |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | |
| brand | AUO |
| diagonal size | 15.6 inch |
| pixel format | 1366(RGB)×768 [WXGA] 100PPI |
| active area | 344.232(H)×193.536(V) mm |
| bezel area | - |
| luminance | 200 cd/m² (Typ.) |
| view direction | 6 o'clock |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| support color | 262K 45% NTSC |
| form style | Slim (PCBA Flat, T≤3.2mm) |
| frame rate | 60Hz |
| model | B156XTN07.0 HW1A (AUO10EC) |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 359.5(H)×223.8(V) ×3.2(D) mm |
| treatment | Glare (Haze 0%) |
| contrast ratio | 500:1 (Typ.) (TM) |
| response time | 8 (Typ.)(Tr+Td) |
| operating mode | TN, Normally White, Transmissive |
| light source | WLED , 15K hours , With LED Driver |
| designed for | Laptop |
| touch panel | Without |
