| Nama Wahi | B156HAN10.2 |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Laptop Gaming |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 1.07B |
| Whakamuri | WLED |
| Atanga | eDP |
| brand | AUO |
| model | B156HAN10.2 |
| diagonal size | 15.6 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×1080 [FHD] 141PPI |
| configuration | RGB Vertical Stripe |
| active area | 344.16(H)×193.59(V) mm |
| outline dim. | 350.66(H)×216.15(V) ×3(D) mm |
| bezel area | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 9 (Typ.)(Tr+Td); 3 (Typ.)(G to G)(OD) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | AHVA, Normally Black, Transmissive |
| support color | 1.07B 100% Adobe RGB |
| light source | WLED , 15K hours , With LED Driver |
| form style | Slim (PCBA Flat, T≤3.2mm) |
| designed for | Laptop Gaming |
| frame rate | 240Hz |
| touch panel | Without |
| interface type | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
