| Nama Wahi | B156HAN10.1 |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Laptop Gaming |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 1.07B |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | AUO |
| panel model | B156HAN10.1 |
| panel size | 15.6" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×1080, FHD, 141PPI |
| pixel format | RGB Vertical Stripe |
| display area | 344.16(W)×193.59(H) mm |
| bezel opening | - |
| outline size | 350.66(W)×216.15(H) ×3(D) mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | AHVA, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 9 (Typ.)(Tr+Td); 3 (Typ.)(G to G)(OD) |
| display colors | 1.07B 100% Adobe RGB |
| lamp type | WLED , 15K hours , With LED Driver |
| frequency | 144Hz |
| touch screen | Without |
| shape style | Slim (PCBA Flat, T≤3.2mm) |
| application | Laptop Gaming |
| signal interface | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
