| Nama Wahi | B156HAN02.2 HWAA |
| Waitohu | AUO |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | AUO |
| panel size | 15.6" |
| resolution | 1920(RGB)×1080, FHD, 141PPI |
| display area | 344.16(W)×193.59(H) mm |
| outline size | 350.56(W)×223.6(H) ×3.2(D) mm |
| brightness | 250 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 262K 46% NTSC |
| frequency | 60Hz |
| shape style | Slim (PCBA Flat, T≤3.2mm) |
| signal interface | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | B156HAN02.2 HWAA (AUO22ED) |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare |
| contrast ratio | 700:1 (Typ.) (TM) |
| display mode | AHVA, Normally Black, Transmissive |
| response time | 25 (Typ.)(Tr+Td) |
| lamp type | WLED , 15K hours , With LED Driver |
| touch screen | Without |
| application | Laptop |
