| Nama Wahi | B154EW02 V0 HW3A |
| Waitohu | AUO |
| Rahi | 15.4 |
| Taupānga | Laptop |
| Whakatau | 1280×800 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | 1 |
| Atanga | LVDS |
| manufacturer | AUO |
| model name | B154EW02 V0 HW3A 1 Compatible |
| screen size | 15.4 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1280(RGB)×800 (WXGA) 98PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 331.2 × 207 (H×V) |
| outline(mm) | - |
| bezel area(mm) | 335.35 × 211.05 (H×V) |
| treatment | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| luminance | 200 cd/m² (Typ.) |
| contrast ratio | 400 : 1 (Typ.) (TM) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| response | 4/12 (Typ.)(Tr/Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K 45% NTSC |
| backlight | 1 pcs CCFL , 10K hours , No Driver |
| outline shape | Wedge (PCBA Bent, T≥5.2mm) |
| used for | Laptop |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 6-bit) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
