| Nama Wahi | B154EW01 V4 |
| Waitohu | AUO |
| Rahi | 15.4 |
| Taupānga | NBPC |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 160 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | B154EW01 V4 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.4 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 331.2×207 mm |
| outline | 344×222×6.5 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| brightness | 160 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit), CIE193152% |
| response time | 4/12 (Typ.)(Tr/Td) |
| viewing angle | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| B154EW01 V3 | AUO | 15.4 | 1280×800 |
| B154EW01 V4 | AUO | 15.4 | 1280×800 |
| B154EW01 V8 | AUO | 15.4 | 1280×800 |
| B154EW02 V3 | AUO | 15.4 | 1280×800 |
| B154EW02 V6 | AUO | 15.4 | 1280×800 |
| B154EW04 V7 | AUO | 15.4 | 1280×800 |
| B154EW08 V0 HW2A | AUO | 15.4 | 1280×800 |
| B154EW08 V1 | AUO | 15.4 | 1280×800 |
| B154EW09 V0 | AUO | 15.4 | 1280×800 |
| B154EW09 V1 | AUO | 15.4 | 1280×800 |
| B140RW01 V2 | AUO | 14.0 | 1600×900 |
| B154SW01 V9 | AUO | 15.4 | 1680×1050 |
| HB140WX1-400 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLB3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLS1 | LG Display | 14.0 | 1366×768 |
| LP154WE2-TLA8 | LG Display | 15.4 | 1680×1050 |
| LP156WHB-TLA1 | LG Display | 15.6 | 1366×768 |
| N133B6-L01 | Innolux | 13.3 | 1366×768 |
| N140BGE-L22 | Innolux | 14.0 | 1366×768 |
| N156HGE-EAL Rev.C1 | Innolux | 15.6 | 1920×1080 |
