| Nama Wahi | B121EW09 V2 |
| Waitohu | AUO |
| Rahi | 12.1 |
| Taupānga | NBPC |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | B121EW09 V2 5 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 261.12×163.2 mm |
| outline | 275.8×178×5.5 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Glare (Haze 0%) |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 30/30/10/20 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S6PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| B121EW02 V0 | AUO | 12.1 | 1280×800 |
| B121EW03 V3 | AUO | 12.1 | 1280×800 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| B121EW03 V9 | AUO | 12.1 | 1280×800 |
| B121EW09 V2 | AUO | 12.1 | 1280×800 |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| B121EW10 V1 | AUO | 12.1 | 1280×800 |
| B121EW10 V2 | AUO | 12.1 | 1280×800 |
| B133HAN02.0 | AUO | 13.3 | 1920×1080 |
| B154EW02 V6 | AUO | 15.4 | 1280×800 |
| CLAA184FP01 | CPT | 18.4 | 1920×1080 |
| LP133WX2-TLGV | LG Display | 13.3 | 1280×800 |
| LP140WH8-TPH1 | LG Display | 14.0 | 1366×768 |
| LP171WP4-TLB4 | LG Display | 17.1 | 1440×900 |
| LTD089EXWS | TOSHIBA | 8.9 | 1280×768 |
| LTM10C348F | TOSHIBA | 10.4 | 800×600 |
| LTN173KT01-D01 | Samsung | 17.3 | 1600×900 |
| N133I5-L01 | Innolux | 13.3 | 1280×800 |
