| Nama Wahi | B121EW03 V7 |
| Waitohu | AUO |
| Rahi | 12.1 |
| Taupānga | NBPC |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 220 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | B121EW03 V7 8 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 261.12×163.2 mm |
| outline | 275.8×178×5.5 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% (Typ.) |
| brightness | 220 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit), CIE193145% |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 40/40/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| B121EW01 V1 | AUO | 12.1 | 1280×800 |
| B121EW03 V0 | AUO | 12.1 | 1280×800 |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| B121EW03 V9 | AUO | 12.1 | 1280×800 |
| B121EW07 V1 | AUO | 12.1 | 1280×800 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B121EW09 V2 | AUO | 12.1 | 1280×800 |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| B121EW10 V1 | AUO | 12.1 | 1280×800 |
| B154EW01 VC | AUO | 15.4 | 1280×800 |
| B156XTK01.0 | AUO | 15.6 | 1366×768 |
| LP121X1-A2M1 | LG Display | 12.1 | 1024×768 |
| LP140WH2-TLS1 | LG Display | 14.0 | 1366×768 |
| LP150X09-B5K8 | LG Display | 15.0 | 1024×768 |
| LP156WF4-SLB1 | LG Display | 15.6 | 1920×1080 |
| LP171WP7-TLB1 | LG Display | 17.1 | 1440×900 |
| LTM10C348F | TOSHIBA | 10.4 | 800×600 |
| LTN156AT05-W01 | Samsung | 15.6 | 1366×768 |
| N141C1-L02 | Innolux | 14.1 | 1440×900 |
