| Nama Wahi | B116XTN02.5 |
| Waitohu | AUO |
| Rahi | 11.6 |
| Taupānga | Laptop Netbook PC |
| Whakatau | 1366×768 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | AUO |
| screen size | 11.6 inch |
| pixel number | 1366(RGB)×768 (WXGA) 135PPI |
| active area(mm) | 256.125 × 144 (H×V) |
| bezel area(mm) | - |
| luminance | 250 cd/m² (Typ.) |
| viewing angle | 45/45/15/35 (Typ.)(CR≥10) |
| good view at | 6 o'clock |
| color depth | 262K 45% NTSC |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| refresh rate | 60Hz |
| signal type | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | B116XTN02.5 (AUO255C) |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 278 × 168 × 3 (H×V×D) |
| treatment | Antiglare |
| contrast ratio | 400 : 1 (Typ.) (TM) |
| response | 8 (Typ.)(Tr+Td) ms |
| work mode | TN, Normally White, Transmissive |
| backlight | WLED , 15K hours , With LED Driver |
| used for | Laptop Netbook PC |
| touchscreen | Without |
