| Nama Wahi | B116XAK01.2 |
| Waitohu | AUO |
| Rahi | 11.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | AUO |
| screen size | 11.6 inch |
| pixel number | 1366(RGB)×768 (WXGA) 135PPI |
| active area(mm) | 256.125 × 144 (H×V) |
| bezel area(mm) | - |
| luminance | 235 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 262K 50% NTSC |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| refresh rate | 60Hz |
| signal type | eDP (1 Lane) , eDP1.2 , 40 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
| model name | B116XAK01.2 (AUO125C) |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 278 × 168.02 × 3.2 (H×V×D) |
| treatment | Antiglare, Hard coating (3H) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| response | 27 (Typ.)(Tr+Tf) ms |
| work mode | AHVA, Normally Black, Transmissive |
| backlight | WLED , 15K hours , With LED Driver |
| used for | Laptop |
| touchscreen | On-Cell Touch |
