| Nama Wahi | B116XAB01.3 |
| Waitohu | AUO |
| Rahi | 11.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD, Assemb |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| brand | AUO |
| model | B116XAB01.3 (AUO288C) |
| diagonal size | 11.6 inch |
| type | a-Si TFT-LCD, Assembly |
| pixel format | 1366(RGB)×768 [WXGA] 135PPI |
| configuration | RGB Vertical Stripe |
| active area | 256.125(H)×144(V) mm |
| outline dim. | 284.85(H)×189.84(V) ×4.2(D) mm |
| bezel area | - |
| treatment | Glare (Haze 0%), Hard coating (7H) |
| luminance | 220 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 27 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | - |
| support color | 16.7M 50% NTSC |
| light source | WLED , 15K hours , With LED Driver |
| form style | - |
| designed for | Laptop |
| frame rate | 60Hz |
| touch panel | On-Cell Touch |
| interface type | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
