| Nama Wahi | B116XAB01.2 |
| Waitohu | AUO |
| Rahi | 11.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | Assembly , a-Si TF |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | AUO |
| screen size | 11.6 inch |
| pixel number | 1366(RGB)×768 (WXGA) 135PPI |
| active area(mm) | 256.125 × 144 (H×V) |
| bezel area(mm) | - |
| luminance | 220 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 262K 50% NTSC |
| outline shape | - |
| refresh rate | 60Hz |
| signal type | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | B116XAB01.2 (AUO125C) |
| screen type | Assembly , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 287.7 × 185.6 × 4.2 (H×V×D) |
| treatment | Glare (Haze 0%), Hard coating (7H) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| response | 27 (Typ.)(Tr+Td) ms |
| work mode | - |
| backlight | WLED , 15K hours , With LED Driver |
| used for | Laptop |
| touchscreen | On-Cell Touch |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW1A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW4A | AUO | 11.6 | 1366×768 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| B116XW01 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116XW05 V001 | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
