| Nama Wahi | AT101WSM-NW0-3800(3900) |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | CNS |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 600:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | BOE |
| panel model | AT101WSM-NW0-3800(3900) |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.1 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 222.72×125.28 mm |
| outline | 235×143×4.8 mm |
| surface | Antiglare (Haze 25%) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| response time | 25 (Typ.)(Tr+Tf) |
| viewing angle | 80/80/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S7PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 60 pins |
| input voltage | 3.3/9.6V (Typ.)(VDD/AVDD) |
| application | CNS |
