Innolux AT056TN04 V.6 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


AT056TN04 V.6

AT056TN04 V.6
AT056TN04 V.6
AT056TN04 V.6
AT056TN04 V.6 thumb AT056TN04 V.6 thumb AT056TN04 V.6 thumb
Waitohu
Innolux
Rahi
5.6
Taupānga
VOIP
Whakatau
320×234
Te tito
LCM
Tirohanga
200
CR
300:1
Nga Tae
Full color
Whakamuri
WLED
Atanga
Analog
In Stock
2300
Whakatakotoranga

Nama Wahi AT056TN04 V.6
WaitohuInnolux
Rahi5.6
TaupāngaVOIP
Whakatau320×234
Te titoLCM
Tirohanga200
CR300:1
Nga TaeFull color
WhakamuriWLED
AtangaAnalog
panel brandINNOLUX
panel modelAT056TN04 V.6
panel type a-Si TFT-LCD , LCM
panel size5.6 inch
resolution320(RGB)×234
display modeTN, Normally White, Transmissive
active area113.28×84.708 mm
outline126.5×100×6 mm
surfaceAntiglare
brightness200 cd/m² (Typ.)
contrast ratio300:1 (Typ.)
display colorsFull color
response time15/20 (Typ.)(Tr/Td)
viewing angle65/65/45/65 (Typ.)(CR≥10)(L/R/U/D)
lamp type2S7PWLEDWithout Driver
signal interfaceTFT Specific Analog RGB, 26 pins
input voltage5.0/5.0/15.0/-10V (Typ.)(VCC/AVDD/VGH/VGL)
applicationVOIP
Tauira Whanau
AT056TN03 Innolux 5.6 320×234
AT056TN04 V.6 Innolux 5.6 320×234
AT056TN52 Innolux 5.6 640×480
AT056TN52 V.2 Innolux 5.6 640×480
AT056TN52 V.3 Innolux 5.6 640×480
AT056TN52 V.4 Innolux 5.6 640×480
AT056TN52 V.5 Innolux 5.6 640×480
AT056TN53 V.1 Innolux 5.6 640×480
FX050605DNCWAG03 Data Image 5.6
Hua wera
AT056TN04 V.6 Innolux 5.6 320×234
PW036XS3 E Ink 3.6 320×234
PW045XS1 E Ink 4.5 320×234
PW045XS2 E Ink 4.5 320×234
TM050QDH01 Tianma 5.0 640×480
TM050QDH11 Tianma 5.0 640×480
ZJ050NA-08C Innolux 5.0 640×480
