| Nama Wahi | AM800480R3TMQW-B2H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM800480R3TMQW-B2H |
| diagonal size | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 133PPI |
| configuration | RGB Vertical Stripe |
| active area | 152.4(H)×91.44(V) mm |
| outline dim. | - |
| luminance | - |
| contrast ratio | 400:1 (Typ.) (TM) |
| view direction | 6 o'clock |
| response time | 5/11 (Typ.)(Tr/Td) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K 45% NTSC |
| light source | WLED |
| weight | - |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
