| Nama Wahi | AM-800600MGTMQW-02H |
| Waitohu | AMPIRE |
| Rahi | 8.4 |
| Taupānga | Industrial |
| Whakatau | 800×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | 12S4P |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel model | AM-800600MGTMQW-02H |
| panel size | 8.4" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 800(RGB)×600, SVGA, 119PPI |
| pixel format | RGB Vertical Stripe |
| display area | 170.4(W)×127.8(H) mm |
| bezel opening | 174.15(W)×131.2(H) mm |
| outline size | 203(W)×145.5(H) ×11.7(D) mm |
| surface | - |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) (TM) |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | - |
| response time | 8 (Typ.)(Tr+Td) |
| display colors | 16.7M |
| lamp type | 12S4P WLED , 50K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | TBD |
| application | Industrial |
| signal interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
