| Nama Wahi | AM-800600K2TMQW-04H |
| Waitohu | AMPIRE |
| Rahi | 10.4 |
| Taupānga | Industrial |
| Whakatau | 800×600 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel size | 10.4" |
| resolution | 800(RGB)×600, SVGA, 96PPI |
| display area | 211.2(W)×158.4(H) mm |
| outline size | 243(W)×185.6(H) mm |
| brightness | 500 cd/m² (Typ.) |
| viewing angle | 70/70/50/60 (Typ.)(CR≥10) |
| best view on | 6 o'clock |
| display colors | 262K 50% NTSC |
| frequency | 60Hz |
| panel weight | - |
| signal interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -35 ~ 85 °C |
| panel model | AM-800600K2TMQW-04H |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 214.8(W)×162.7(H) mm |
| surface | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 5/15 (Typ.)(Tr/Td) |
| lamp type | WLED , 30K hours , With LED Driver |
| touch screen | Without |
| application | Industrial |
