| Nama Wahi | AM-800480L6TZQW-TN0H-I |
| Waitohu | AMPIRE |
| Rahi | 5.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 250:1 |
| Nga Tae | 16.7M |
| Whakamuri | 3S4P |
| Atanga | Parallel |
| manufacturer | AMPIRE |
| model name | AM-800480L6TZQW-TN0H-I |
| screen size | 5.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 188PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 108 × 64.8 (H×V) |
| outline(mm) | 118.5 × 77.1 × 6.44 (H×V×D) |
| bezel area(mm) | 110.6 × 67.4 (H×V) |
| treatment | - |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 250 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 15/35 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | Normally Black, Transmissive |
| color depth | 16.7M 52% NTSC |
| backlight | 3S4P WLED , 30K hours , No Driver |
| mass | - |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | PCAP |
| signal type | Parallel RGB (1 ch, 8-bit) , FPC 45 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
