| Nama Wahi | AM-1280800P4TZQW-T01H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1280×800 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | AMPIRE |
| model | AM-1280800P4TZQW-T01H |
| diagonal size | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×800 [WXGA] 217PPI |
| configuration | RGB Vertical Stripe |
| active area | 149.76(H)×93.6(V) mm |
| outline dim. | 162.3(H)×107.9(V) ×11.76(D) mm |
| bezel area | 152.76(H)×96.6(V) mm |
| treatment | - |
| luminance | 1275 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| operating mode | SFT, Normally Black, Transmissive |
| support color | 16.7M 50% NTSC |
| light source | WLED [5S4P] , 50K hours , With LED Driver |
| weight | - |
| designed for | Industrial Outdoor High Brightness |
| frame rate | 60Hz |
| touch panel | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
