| Nama Wahi | AM-1280800J4TZQW-T00 |
| Waitohu | AMPIRE |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1280×800 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AMPIRE |
| model | AM-1280800J4TZQW-T00 |
| diagonal size | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×800 [WXGA] 149PPI |
| configuration | RGB Vertical Stripe |
| active area | 216.96(H)×135.6(V) mm |
| outline dim. | 231(H)×150(V) ×8.8(D) mm |
| luminance | 300 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | Normally Black, Transmissive |
| support color | 16.7M |
| light source | WLED [3S11P] , 15K hours , With LED Driver |
| weight | TBD |
| designed for | Industrial |
| frame rate | 60Hz |
| touch panel | PCAP |
| interface type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
